Trommel Screen

Trommel screen named rotary screen is widely used for mining sieving and construction waste. It provides a simple, efficient and economical solution to upgrade a wide range of material. This method of screening helps to reduce operating and investment cost and to increase product quality, while allowing rapid and large volume processing.

Get Price Chat Now Send E-mail

Introduction
Parameter
Video
Related Products
Inquiry Now

Introduction

1. Mixing equably and running steadily.

2. Little shock vibration.

3. Conveniently moved or fixed on ground only.

4. Easy sealed and avoid pollution.

5. Widely used in classifying refractory materials, coal, sand stone etc.

6. Long service life.

Parameter

Model	Cylinder size	Slant angle	Drum speed（r/min）	Mesh range（mm）	Maximum feed grain（mm）	Capacity（m³/h）		Power（kw）
Model	Cylinder size	Slant angle	Drum speed（r/min）	Mesh range（mm）	Maximum feed grain（mm）	Mesh （2mm）	Mesh （30mm）	Power（kw）
YTS1030	Φ1x3	5-7°	22.5	2-30	60	10	60	4
YTS1040	Φ1x4	5-7°	25	2-30	60	11	80	4
YTS1230	Φ1.2x3	5-7°	20	2-30	70	12	100	5.5
YTS1240	Φ1.2x4	5-7°	20	2-30	70	14	120	5.5
YTS1250	Φ1.2x5	5-7°	20	2-30	70	15	140	5.5
YTS1530	Φ1.5x3	5-7°	17	2-30	80	18	150	5.5
YTS1540	Φ1.5x4	5-7°	17	2-30	80	18	150	7.5
YTS1550	Φ1.5x5	5-7°	17	2-30	80	20	180	11
YTS1560	Φ1.5x6	5-7°	17	2-30	80	22	200	11
YTS2040	Φ2x4	5-7°	12	5-60	90	25	250	15
YTS2050	Φ2x5	5-7°	12	5-60	90	30	300	15
YTS2060	Φ2x6	5-7°	12	5-60	90	35	350	18.5
